Key Features e’6m

• 250+ milk products per hour- depending on cup size.
• Self-service capability.

525 espresso/hour
at 23 seconds extraction time
or 350 cappuccino/hour/

120 ml (4.0 oz US)
150 hot water units/hour/
200ml (6.8 oz US)

6 espresso or
4 cappuccino and 2 espresso

at the same time

Autosteam, temperature controlled

The e’6m is equipped with an in-built automatic milk heating/frothing module.

Power requirement A

Single-phase 1 x 230 V, 1L-N-PE, 30 A, 50/60 Hz, 5.8 kW

Two-phase 1 x 208 V, 2L-PE, 30 A, 50/60 Hz, 4.9 kW

Three-phase 3 x 230 V, 3L-N-PE, 16 A, 50/60 Hz, 8.6 kW

Power requirement B

Single-phase 1 x 230 V, 1 L-N-PE, 16 A, 50/60 Hz, 3.0 kW

Two-phase 2 x 208 V, 2L-PE, 16 A, 50/60 Hz, 2.5 kW

Water

Stainless steel braided hose length = 2 m with screw G3/8", 0–4 bar

Drain

hose Ø = 16 / 22 mm, length = 2 m

Water quality

Total hardness 5 – 8 °dGH (89 – 142ppm)

Carbonate hardness: max. 6 °dKH (107 ppm)

pH value: optimal 7.0 –7.2

Interfaces

USB, SD-Card, Ethernet, Serial RS-232, CCI (24 VDC, 15 W)

Standby mode

Less than 2 Watts electrical consumption

Front lighting

Full colour LED, all colours and colour gradient adjustable

Specifications

Weight

150 kg (330 lb)

Brew chamber

3 x up to 24 g

Grinding

4 x super drive ceramic grinder disk

User interface

3 x 8" colour touch screen

Bean hoppers

4 x 1.5 kg (3.3 lb)

Coffee spout height

65 mm to 165 mm (2.55 to 6.49 inch)

Coffee boiler size

3 x 1.6 Liter (0.42 gal US)

Steam boiler size

5.6 Liter (1.48 gal US)

Options for e’6m

E’FOAM

This function enables machine operators to produce barista quality frothed milk at the touch of a button.

DECAFFEINATED POWDER CHUTE

This option enables the user to produce decaffeinated products without mobilising a dedicated bean hopper.

BEAN HOPPER LOCK

This option protects the integrity/quality of the beans, prevents shrinkage.

UNDER COUNTER GROUND COFFEE DISPOSAL

In high volume sites, this option promotes continuous operation, without having to empty out the coffee grounds drawer.

CCI / CSI CONNECTIVITY FOR CREDIT SYSTEMS

This interface capacity enables Eversys equipment to be linked to payment mechanisms.

LAN AND ETHERNET

LAN, a more stable option than WIFI, enables the machine to be connected/accessed via the internet.
